CCTV Power supply
9 Channels
Powering multiple cameras could not be easier ! Our line of Professional CCTV Power Supplies give installers what they expect when it comes to power supplies, quality and reliability.CCTV Power Supply Unit 12VDC,20A,9P • Power up to 9 CCTV CCTV surveillance cameras • 12 Volts DC • 20mp total output • Max output current up to 2.2 Amp/Channel • 9 individually PTC auto-reset fuses protected outputs
The9CH Power Supply Unit (CCTV Central Power) offers a more professional alternative to individual power adapters, for powering 9 CCTV cameras. Mounting flange design allows easy wall mounting.
Features:
General protection: each output has independent glass tube fuse and LED indicator, when problem occurs, only affect the independent output, other outputs still working.
Circuit short protection: when short condition occurs, independent PTC fuse will open the circuit, when condition removed, PTC fuse will automatically back to close.
High voltage protection: when high voltage occurs, the surge protection will be hit through to protect the connected device.
Over Current protection: when over current occurs, the power supply will automatically switch to self-protection status, when condition removed, then switch back to normal.
Application: CCTV Camera, PTZ, IR Illuminator, Access Control, etc.
Technical Specification:
Input Voltage - AC 100-240V
Input Voltage Frequency ? 50/60Hz
Output Voltage - DC 12V
Total Output Current - 10A
Total Outputs - 120W
Fuse Type - Glass Fuse
Fuse Rating - 0.5 Amps / 250VAC.
